Philips 5000 Series DDL505-5HBS Smart Rim Door Lock

Upgrade your entrance with the Philips DDL505-5HBS 5000 Series Smart Rim Door Lock – a modern keyless entry solution designed for convenient everyday access and reliable outdoor use.

Multiple Keyless Access Options

Choose the access method that suits you:

• Fingerprint recognition
• PIN code access
• Key tag access
• Temporary PIN code support
• Philips Home Access App functionality

The lock can store up to 100 fingerprints, 100 key tags and 20 user PIN codes, making it suitable for families, homes and properties requiring access for multiple users.

Designed for Outdoor Conditions

The DDL505-5HBS features IP55-rated protection against dust and water and is designed for use in demanding outdoor environments.

The lock is designed to operate in temperatures ranging from -25°C to 70°C.

Automatic Locking

Hall sensor technology allows the lock to detect when the door has been closed.

When Auto Mode is enabled, the deadbolt automatically engages after the door closes, helping prevent the door from accidentally being left unlocked.

Dual Verification Mode

For additional security, Dual Verification Mode can require two registered authentication methods before unlocking.

Authentication methods include:

• Fingerprint
• PIN code
• Key tag

Smart App Functionality

The DDL505-5HBS works with the Philips Home Access App.

With the appropriate compatible gateway, smart functionality can include access to lock operation records, entry logs, doorbell notifications and security alerts.

Please note: some remote smart functions require a compatible gateway, which may be sold separately.

Battery Powered

The lock operates using 4 × AA alkaline batteries, with battery life of up to approximately 6 months under typical testing conditions.

A 5V power bank can also be used to provide emergency power if required.

Installation Requirements

Australian installation specifications:

• Door thickness: 35–50 mm
• Lock stile: 180 mm
• Backset: 50 mm

Please check your door measurements and installation requirements carefully before purchasing.

Professional installation may be required depending on your existing door and lock configuration.

Before you buy: confirm door compatibility

Philips identifies the DDL505-5HBS as a smart rim lock. Before ordering, have your installer confirm the following against the manufacturer’s installation guide for the supplied model:

• ☐ Door thickness, stile clearance, backset and required drilling dimensions.
• ☐ Door material, opening direction and frame/strike mounting suitability.
• ☐ Whether existing deadbolt holes or rim-cylinder hardware can be reused.
• ☐ Emergency access procedure, including whether physical-key override is available.
• ☐ Required installation parts and a locksmith willing to install and service this model.

Installation dimensions, cylinder compatibility and physical-key access have not yet been manufacturer-verified for this checklist. Do not assume this is a direct replacement for your existing lock.

Product Details

• Brand: Philips
• Series: 5000 Series
• Model: DDL505-5HBS
• Type: Smart Rim Door Lock
• Colour: Sky Grey
• Material: Aluminium Alloy / Tempered Glass
• Weather Protection: IP55
• Power Source: Battery
• Battery Type: 4 × AA Alkaline Batteries
• Fingerprint Capacity: Up to 100
• Key Tag Capacity: Up to 100
• User PIN Capacity: Up to 20
• Operating Temperature: -25°C to 70°C
• Compatible App: Philips Home Access App
• EAN / UPC: 6971318505089

Key Features

• Fingerprint unlocking
• PIN code unlocking
• Key tag unlocking
• Multiple-user access
• Temporary PIN code support
• Automatic locking
• Dual verification mode
• Philips Home Access App support
• IP55 dust and water protection
• Wide operating temperature range
• Low battery warning
• Emergency power capability
• Modern Philips 5000 Series design

Important Compatibility Information

Please confirm that this lock is suitable for your particular door before purchasing.

Door construction, existing lock cut-outs, door thickness, stile dimensions and backset can affect compatibility.

Some app and remote functionality may require additional compatible equipment, such as a gateway, which may not be included with the lock.

Professional installation is recommended where you are unsure about compatibility or installation requirements.
